FrSky Receiver TFR6A

FrSky TFR6-A 7CH 2.4Ghz Receiver Futaba FASST Compatible (Horizontal Connectors)

The TFR6-A is a high quality 7 channel receiver from FrSky that is compatible with all Futaba FASST series radios. The TFR6-A features end pins to enable even more compact installation.

The TFR6-A supports two selectable failsafe setting options, either set failsafe positions for each channel on your transmitter, or set the failsafe on the TFR6-A.

The failsafe function is supported for all channels.

Compatibility:

• FASST 2.4G: Air Systems (7CH Mode/Multi Mode) 6EX, 7C, TM-7, TM-8, T8FG, T10C, TM-10, T10CG, T12Z, T12FG, TM-14, T14MZ etc.
• FrSky TF Modules: TF-8M, TF-14M

Features:

• Light weight and compact
• End mounted connectors
• Two selectable failsafe setting options

Specifications:

• Number of Channels: 7
• Operating Voltage Range: 3.5V to 10V
• Operating Temperature Range: -10 to 60 deg Celcius
• Dimension: 46 x 23 x 14mm
• Weight: 10g
